ANALOG TRANSMITTER P510A
$230.00
Analog Transmitter P510A develops a 4-20 milliamp output proportional to either a 0 to 5VDC control input or to the position of a 10K potentiometer connected to the input. The unit must be powered with 9 to 30VDC power.
See the data sheet for additional details including typical installation diagrams and wiring information.
Full Description
USING A POTIOMETER INPUT AS SHOWN BELOW, THE OUTPUT IS 4-20 MILLIAMPS.
ALTERNATIVELY, 0 TO 5VDC CONTROL SIGNAL MAY BE USED INSTEAD OF THE POT. CONNECT THE CONTROL SIGNAL TO TERMINAL 1 AND THE COMMON TO TERMINAL 2. USE THE JUMPER AS SHOWN BELOW FOR AN OUTPUT SELECTION OF 0 TO 20 MA OR 4 TO 20 MA.
THE UNIT MUST BE POWERED WITH 9 TO 30VDC ON TERINALS 7 (+) AND 8 (-).
